Description
| Operating Principle: | Oscillometric Method |
| Indicator: | 15 Digits Liquid Crystal Display |
| Pressure Indicating Range: | 3 to 300mmHg (cuff pressure) |
| Measuring Range: | 50 to 250mmHg (systolic), 40 to 180mmHg (diastolic), 40 to 160 bpm (pulse rate) |
| Accuracy: | ± 3mmHg (cuff pressure), =-5% of reading (pulse rate) |
| Inflation: | Automatic Inflation (FUZZY) |
| Deflation: | Automatic (electric control valve) |
| Exhaust: | Automatic Exhaust Valve |
| Power Supply | Four 1.5 volt Lr6 (AA alkaline) batteries or AC adaptor ADP-W5 series |
| Power Consumption: | 4W (max) |
| Electric Rating: | DC6V/4″, with four LR6 batteries Adapter: AC100-240V, 50-60Hz, 0.12A Unit: DC6V,===500mA, with designated AC adapter |
| Memory: | 2 banks, each stores 60 reading |
| Operating Condition: | +10°C to +40°C, 15% to 85% RH (noncondensing) |
| Transportation / Storage Condition: | -20°C tro +60°C, 10% to 95% RH (noncondensing) |
| Cuff: | Covergae arm circumference: 22 to 42cm applied part; BF |
| Main Unit: | Weight: Approx. 250g(without batteries) Size: Approx. 115 x 115 x 65.9mm (W x D x H) |
| Protection against harmful ingress of water: | IPXO (IEC 60601-1) |
| Protection against electric shock: | Internally powered equipment / Class II equipment, Type BF applied part |
| Mode of Operation: | Continuous Operation |
| Classification: | Class II / Internally powered equipment |
